In today’s competitive manufacturing landscape, die casting operations face unprecedented challenges, including extreme operating conditions, increasing precision requirements, and the need for maximum production efficiency. The ES600 series was developed specifically to address these challenges with innovative servo motor technology designed for the unique demands of the die casting industry.
Technical Excellence Meets Practical Application
The ES600 series represents the pinnacle of die casting machine technology. Our liquid-cooled embedded servo motors are engineered to deliver exceptional performance in even the harshest manufacturing environments.
| Pressure |
oil pump displacement |
Motor |
Servo drive |
| cc |
Model |
Model |
Parameter |
Model |
Parameter |
| 16 |
32 |
EP18-70F17K |
71Nm,1700rpm |
ES600T032 |
15KW |
| 16 |
40 |
EP18-88F17K |
88Nm,1700rpm |
ES600T037 |
18.5KW |
| 16 |
50 |
EP18-105F17K |
105Nm,1700rpm |
ES600T045 |
22KW |
| 16 |
63 |
EP18-128F17K |
128Nm,1700rpm |
ES600T060 |
30KW |
| 16 |
80 |
EP18-168F17K |
168Nm,1700rpm |
ES600T075 |
37KW |
| 16 |
100 |
EP25-218F17K |
318Nm,1700rpm |
ES600T091 |
45KW |
| 16 |
125 |
EP25-267F17K |
267Nm,1700rpm |
ES600T112 |
55KW |
The ES600 series offers multiple structural configurations to meet your specific application requirements:
- Flat Key Design – Simple, reliable connection for standard die casting applications
- Spline Design – High torque transmission with axial movement capability
- Single-Output Shaft – Compact design for space-constrained installations
- Double-Output Shaft – Versatile solution for complex drive systems
The innovative embedded structure significantly improves weak magnetic overspeed performance, allowing for higher operating speeds and increased production throughput. This translates directly to improved productivity and profitability.
Advanced materials and proprietary design techniques ensure excellent resistance to demagnetization, even in the high-temperature, high-stress environments typical of die casting operations. This results in longer motor life and reduced maintenance costs.
With the ability to handle short-term overloads up to 3 times rated capacity at speeds below 80% of rated speed, the ES600 series easily handles the intermittent high-load demands of modern die casting cycles.
The specialized liquid cooling system maintains optimal operating temperatures, ensuring consistent performance even in the most demanding heat-intensive environments.
The ES600 series is ideally suited for a wide range of die casting applications:
- Lightweight aluminum components
- Electric vehicle structural parts
- Transmission and engine components
- High-strength, lightweight parts
- Precision aerospace castings
- Complex geometry components
- Precision housing components
- Heat sink manufacturing
- Connector and fitting production
- Heavy machinery components
- Hydraulic system parts
- Gearbox housings
